Types of Privacy Films

Type Principle Features Typical Applications
Micro-Louver Type Uses micro-louver structures to restrict the light emission angle (e.g., ±30° or ±45°) Mainstream type; clear front view, darkens when viewed from the side Smartphones, laptops, ATMs, car displays, industrial monitors
Polarization Type Uses a polarizer to restrict the light vibration direction Higher cost, slightly lower transmittance; suitable for high-contrast displays High-end industrial displays, medical devices
Diffusion Type Scatters light with micro-particles to reduce side visibility Low cost, modest privacy effect, significant brightness reduction Price-sensitive products
Hybrid Type Combines micro-louver with polarizer or anti-reflection Offers multiple functions: privacy, anti-glare, anti-fingerprint High-end laptops, tablets, car infotainment screens



Currently, we mainly use micro-louver type privacy films. The following structure diagrams illustrate the principle:

Structure diagrams of micro-louver privacy film

The micro-louver layer resembles tiny blinds (spacing only tens of microns) that allow light to pass in a specific direction (vertical or ±30°).

  • Front view: Light passes directly → screen content is clear
  • Side view: Light blocked by louvers → screen darkens or becomes invisible

Typical privacy angles:

  • Horizontal: 30°, 45°, 60°
  • Vertical: Up/down privacy is also possible (used for laptops, ATMs, etc.)

From the third structural diagram (this is an automotive light-controlled privacy film), we can see that there are AG layers on both the top and bottom of the privacy film. This type of structure is commonly referred to as a Double-sided AG Privacy Film.

Features:

  • Double-sided anti-glare (AG): Reduces reflections on both surfaces, improves display visibility, scratch-resistant
  • Privacy protection: Darkens at side angles to prevent viewing by others
  • Surface feel: Fine matte AG texture, good anti-fingerprint performance
  • Applications: Outdoor high-brightness TFT LCDs, car displays, industrial monitors, laptops



Structure of Privacy Film

Privacy films are multi-layer composites. Key layers include the base layer, micro-louver layer, OCA, plus optional layers like hard coating and adhesive layers.

  1. Hard Coating Layer: Scratch-resistant, increases surface hardness (typically 3H–9H)
  2. Base PET Layer: Provides mechanical strength and stability
  3. Micro-Louver Layer: Core privacy structure controlling light direction
  4. Optical Adhesive (OCA): Bonds layers while maintaining optical clarity
  5. Adhesive/Silicone Layer: Allows attachment to the screen surface, can be removed and reapplied without residue



Installation Methods

  • Surface-mounted: Uses silicone or OCA; easy to apply, removable; reduces surface hardness
  • Embedded: Laminated inside the LCD module; higher protection, does not affect surface hardness
  • Magnetic/Clip-on: External, detachable; often used for monitors

In our industry, the simplest approach is to attach the privacy film directly to the display surface:

  • Pros: easy, low cost
  • Cons: reduces surface hardness
    Another method is to insert the film between the backlight and LCD glass:
  • Pros: preserves surface hardness
  • Cons: adds to assembly complexity



Key Parameters of Privacy Film

Privacy film parameters fall into four categories: optical, physical structure, environmental/ durability, and surface functions.

  1. Optical Parameters:

  • Visible Light Transmittance (VLT): Ratio of visible light passing through; higher value → brighter screen.
    • Typical range: 50%–85%
  • Viewing Angle / Privacy Angle: Screen is clear at center, darkens beyond this angle.
    • Typical range: ±30°, ±45°, ±60°
  • Haze: Degree of light scattering; higher haze reduces glare but slightly lowers clarity.
    • Typical range: varies by film type; 2%–15% for an AG surface, 10%–40% for the double-sided AG film below
  • Reflectance: Surface reflection rate; affects anti-glare performance.
    • Typical range: 1%–10%
  • Polarizer Compatibility: Must match TFT LCD polarizer to avoid distortion or color shift
    • Typical range: To Be Verified by Testing

Optical parameters are our main focus. The following are the specifications for the double-sided anti-glare privacy film:

  • Total Light Transmittance: ~70%–80% (high-transmittance privacy film); e.g., a 1000 nits display may drop to 700 nits
  • Transmittance: 70%–80% indicates a high-transmittance privacy film.
  • Haze: 10%–40% clearly shows that the surface has been treated with AG (anti-glare) coating.
  • Up/down (Vertical Viewing Angle) 30° transmittance ≤15%:
    • Up/down 30° angle (±30°): Refers to the viewing angle 30° above or below the vertical center of the screen (vertical privacy direction).

At this angle, visible light passing through the privacy film is less than 15% of the front brightness.

This indicates that the film provides vertical (up/down) privacy protection.

  • Transmittance <15%: At this angle, the intensity of visible light passing through the privacy film is less than 15% of the front-facing brightness.

This means that the privacy film provides vertical (up/down) privacy protection.

Item Unit Typical Value Testing Standard
Thickness of Functional Layers µm 370±20 GB/T 33399
Total Light Transmittance % ≥70 GB/T 2410
Haze % 10~40 GB/T 2410
Transmittance at 30°

Vertical Viewing Angle

% ≤15 /



PS: The table below shows the characteristics of privacy films with different Transmittance levels. This is also helpful for our selection process.

Type Transmittance (Approx. Range) Features
Standard HD Film 90%–95% Clear display, minimal brightness loss
Privacy Film (Standard) 50%–70% Noticeable viewing angle limitation, screen slightly darkened
High-Transmittance Privacy Film 70%–80% Maintains privacy while minimizing brightness loss
Strong Privacy Film 40%–55% Strong privacy effect, but darker screen and deeper colors



  1. Physical / Mechanical Parameters

  • Total Thickness: Overall thickness including PET substrate, AG layer, privacy layer, etc.
    Typical range: 0.1–0.5 mm
  • Base Material: PET, PC, PMMA, Glass Composite, etc.
    Typical range: Depends on application
  • Surface Hardness: Scratch resistance, usually expressed in pencil hardness (H)
    Typical range: 3H–9H
  • AG Layer Roughness (Ra): Affects haze, feel, and anti-reflection performance
    Typical range: 0.02–0.1μm
  • Adhesive Type: Silicone, OCA, or adhesive-free electrostatic



  1. Durability / Environmental Tests

  • Operating / Storage Temperature Range: Typically -20℃ to +80℃
  • Humidity Resistance: No bubbling or discoloration after 60℃ / 90% RH test
  • UV Resistance: No yellowing after prolonged exposure
  • Adhesion Strength: Strength of adhesive bonding to the screen



  1. Surface Treatments / Functionalities

  • Anti-Glare (AG): Reduces reflection, improves outdoor readability
  • Anti-Fingerprint (AF): Oleophobic/hydrophobic, easy to clean
  • Anti-Scratch: Enhances wear resistance
  • Anti-Reflection (AR): Improves optical contrast
  • Anti-Static: Prevents dust attraction



The table below shows how to evaluate or select different types of privacy films based on their parameters.

Dimension Micro-Louver Polarization Diffusion Hybrid
Viewing Angle Clearly specified ±30° / ±45° Smooth decay curve Not specified, only “blurred” Both ± angles + polarizer transmittance data
Transmittance (Tt) 60–75% (relatively high) 35–50% 50–70%, haze > 60% 40–60% (depends on structure)
Haze 10–25% 20–40% 60–90% 30–60%
Contrast Retention ≥90% (front view) ~80% <70% 70–90%
Thickness / Layers 0.25–0.4 mm, double or triple layer ~0.2 mm, with polarizer <0.2 mm, single or double layer >0.4 mm, multi-layer stack
Microstructure Feature Visible parallel micro-groove array No micro-grooves, anisotropic film Rough matte Micro-grooves + polarizer layers

Should you have any questions about privacy film, please consult our engineering.

Frequently asked questions

What types of privacy film are there?

Micro-louver, polarization, diffusion and hybrid types. Micro-louver is the mainstream type: the front view stays clear and the screen darkens from the side. Polarization types cost more and transmit slightly less light. Diffusion types are low cost with a modest privacy effect and a significant brightness reduction.

How does a micro-louver privacy film work?

A micro-louver layer works like tiny blinds with spacing of only tens of microns. It passes light in a set direction, so the screen is clear from the front and darkens or becomes invisible from the side. Typical horizontal privacy angles are 30, 45 and 60 degrees.

How is privacy film installed?

Surface-mounted film (silicone or OCA) is easy and low cost but reduces surface hardness. Placing the film between the backlight and the LCD glass preserves surface hardness but adds assembly complexity. Magnetic and clip-on types are detachable and are often used for monitors.

Does privacy film reduce display brightness?

Yes. A high-transmittance privacy film is about 70% to 80% total light transmittance, so, for example, a 1000 nit display may drop to about 700 nits.
