TFT Display vs Super AMOLED, which is Better?
IPS TFT and Super AMOLED compared on light source, thickness, contrast, viewing angle, color, sunlight readability and power consumption.
On this page
Thanks for the display technology development, we have a lot of display choices for our smartphones, media players, TVs, laptops, tablets, digital cameras, and other such gadgets. The most display technologies we hear are LCD, TFT, OLED, LED, QLED, QNED, MicroLED, Mini LED etc. The following, we will focus on two of the most popular display technologies in the market: TFT Displays and Super AMOLED Displays.
TFT Display
TFT means Thin-Film Transistor. TFT is the variant of Liquid Crystal Displays (LCDs). There are several types of TFT displays: TN (Twisted Nematic) based TFT display, IPS (In-Plane Switching) displays. As the former can’t compete with Super AMOLED in display quality, we will mainly focus on using IPS TFT displays.
Super AMOLED
OLED means Organic Light-Emitting Diode. There are also several types of OLED, PMOLED (Passive Matrix Organic Light-Emitting Diode) and AMOLED (Active Matrix Organic Light-Emitting Diode). It is the same reason that PMOLED can’t compete with IPS TFT displays. We pick the best in OLED displays: Super AMOLED to compete with the LCD best: IPS TFT Display.
Super AMOLED vs IPS TFT
| AMOLED | IPS TFT | |
| Light Source | it emits own light | It requires a backlight |
| Thickness | Very slim profile | Thicker because of the backlight |
| Contrast | Higher because of dark background | Lower because of backlighting |
| Viewing Angles | All around | It has color changes at extreme viewing angles |
| Colors | Bright and vibrant colors available | Not the same good compared with AMOLED |
| Super dark color | Easily available dark background | Difficult because the backlight leakage |
| Super White Color | Difficult to get because color mix difficult which can look yellowish | Easily avaible by using white LED backlight |
| Sunlight Readable | Needs to drive hard and difficult | Easily and low cost to get by using high brightness backlight, transflective displays, optical bonding and surface treatment |
| Power Consumption | Lower because of selective display area and better battery life | Higher because of backlight on |
| Life time | Shorter, especially affected by the presence of water | Longer |
| Cost | Very high | Very competitive prices |
| Availability | Limited sizes and manufacturers | Widely available on different sizes and many manufacturers to choose from |
If you have any questions about Orient Display displays and touch panels. Please feel free to contact: Sales Inquiries, Customer Service or Technical Support.
Frequently asked questions
What is the difference between a TFT display and Super AMOLED?
Which has better contrast and viewing angles, AMOLED or IPS TFT?
Which is better in sunlight, AMOLED or IPS TFT?
Which uses less power, AMOLED or IPS TFT?
How do AMOLED and IPS TFT compare on lifetime, cost and availability?
