New 7.0″ Sunlight Readable IPS, 1024×600, 1000 Nits
$48.60CONTACT FOR VOLUME PRICING
76 in stock
Ships from SeattleKey specs
- Model / Series Name: AFY1024600A2-7.0INTH
- Diagonal Dimension (Inches): 7.0
- Dots WxH: 1024 x 600
- Module Size WxHxD max (mm): 165.00 x 100.00 x 5.65
- Display Mode: IPS / Normal black / Transmissive
Volume pricing
| Quantity | Unit price | Save |
|---|---|---|
| 1–24 | $48.60 | — |
| 25–49 | $46.47 | −4% |
| 50+ | $44.33 | −9% |
Contact us for larger volume orders and any other enquiries.
Specifications
A simple 7.0″ High Brightness / Sunlight Readable IPS Module, Transmissive / All Viewing Direction / Normal Black with 1024 x (RGB) x 600 dots.
Sunlight readable ips 1024×600 – 7 Inch IPS TFT Display details
- 7.0″ IPS, 1024 x (RGB) x 600
- High Brightness / Sunlight Readable IPS
- Transmissive / Normal Black
- ALL Viewing Direction
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- ROHS Compliant
| Model / Series Name | AFY1024600A2-7.0INTH |
| Diagonal Dimension (Inches) | 7.0 |
| Dots WxH | 1024 x 600 |
| Module Size WxHxD max (mm) | 165.00 x 100.00 x 5.65 |
| Display Mode | IPS / Normal black / Transmissive |
| IC | EK79001Â Â EK73215BCGA |
| Interface Type | LVDS |
| Logic Power Supply Voltage | 3.3 |
| Backlight | 30 Chip White LED, lf = 150mA |
| Luminance | 1000 cd/m2 |
| Touch Panel | None |
Check Also: Arduino IPS TFT 240×240
Custom Made Options
FPC or Cable Customization
Obtain a customized cable or FPC to enhance the security and efficiency of your connections, by adjusting cable length, position, pinout, or adding extra connectors.
Touch Panel with Optical Bonding
Improve your user experience by incorporating either capacitive or resistive touch screen. We will tailor the thickness, color or shape of the touch panel and cover lens to seamlessly integrate with your design with or without OCA or OCR bonding.
GUI or Interface Customization
Select the most suitable connection or GUI interface. We can integrate various interfaces such as HDMI, USB, SPI, I2C, UART, MCU, VGA, and others into your display to fulfill your design objective.
