OD-204
OD-204 (2-Digit LCD Glass Panel)
$2.00CONTACT FOR VOLUME PRICING
Free ground shipping on US orders over $50 (excl. AK and HI)
1087 in stock
Ships from SeattleNo MOQ on standard partsFree shipping over $5024-hour sample shipping from US stock
Key specs
- TN LCD Glass Panel
- Positive Display
- 6 o’clock Viewing Direction
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- Reflective Polarizer
- ROHS Compliant
Need volume, a modified part or a lead time?
Need a display built to your own spec? Start a custom project and our engineers respond within one business day.
Start a Custom ProjectSpecifications
Downloads & resources
A simple TN OD-204 2 Digit LCD Glass Panel with Zebra Connection. This LCD Glass has elastomers (Zebra Strips), silicon strips of alternating conductors for easy compression between the LCD and the circuit board. This LCD requires a bezel to squeeze the display and the circuit board together. Please contact us anytime if you want to customize this display with a bezel.
- TN LCD Glass Panel
- Positive Display
- 6 o’clock Viewing Direction
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- Reflective Polarizer
- ROHS Compliant
| Model / Series Name | OD-204 |
| No. of Digitals | 2 |
| LCD Mode | TN Positive |
| Polarizer Type | Reflective |
| Glass Size WxH (mm) | 8.00 x 10.00 |
| View Area WxH (mm) | 6.00 x 5.50 |
| No of Segments (each digit) | 7 |
| Digital Height (mm) | 4.00 |
| Operating Voltage | 3.0 |
| Driving Method | Static |
| Connector | Zebra |
Please also check out our other products under this category – LCD Glass Panels. If none of these products meet your needs, we can customize it according to your technical specifications.
Additional information
| Weight | 0.03 lbs |
|---|---|
| Dimensions | 10.00 × 8.00 × 0.1 mm |
| Display mode | TN – Positive |
| Display type | Glass Panel |
| Polarizer type | Reflective |
