1.54″ E-Paper, 200×200, All Viewing Angle, SPI Interface
$7.20CONTACT FOR VOLUME PRICING
15 in stock
- EPD – Electrophoretic Display (Active Matrix)
- Diagonal Dimension: 1.54 Inch
- Resolution: 200 x 200 pixels
- Interface: 3-/4-wire SPI
- Polarizer: Reflective
- Viewing Direction: All
- Touch Panel: None
Pricing table
| Quantity | Unit Price |
|---|---|
| 25-49 | $6.34 |
| 50- | $5.47 |
Contact us for larger volume orders and any other enquiries.
Description
1.54″ E-Paper (Black and White) Display, All Viewing Direction with 200 x 200 dots, 3-/4-wire SPI Interface.
The highest quality product at the lowest price. Ships from the USA.
- 1.54″ E-Paper, 200 x 200
- Reflective
- All Viewing Direction
- Operating Temp: 0°C to 50°C
- Storage Temp: -25°C to 70°C
- ROHS Compliant
Download Product References Below
Product Datasheet: AES200200A00-1.54ENRS
Controller: SSD1681
Optional Accessory: TBD
| Model / Series Name | AES200200A00-1.54ENRS |
| Diagonal Dimension (Inches) | 1.54 |
| Dots WxH | 200 x 200 |
| Module Size WxHxD max (mm) | 31.80×37.32×0.98 mm |
| Display Mode | EPD – Electrophoretic Display (Active Matrix) / Reflective |
| IC | SSD1681 |
| Interface Type | 3-/4-wire SPI |
| Logic Power Supply Voltage | 1.8 |
| Backlight | None |
| Luminance | None |
| Touch Panel | None |
These are just few of our famous display modules; we still have a lot of products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
Additional information
| Weight | 0.005 lbs |
|---|---|
| Dimensions | 31 × 51 × 1 mm |
| Diagonal Size (Inch) | 1.54 |
| displaytype | |
| polarizertype | |
| resolution | |
| Touch Panel | None |
| viewingdirection |
