Orient Display is a company that specializes in manufacturing LCD glass, LCD display modules, color TFT displays, touch panels and embedded displays with competitive prices. The company was founded in 1996 by specializing in fields of production, R&D and quality controls. Thanks for the management and employees’ continuous hardworking and enormous effort and shareholder continuous investment over years, Orient Display factory is now the world’s lead monochrome displays, TFT LCD displays and touch panel manufacturer in flat panel industry and is listed as a public company in China stock market. Now, Factories have complete quality and environment management system, ISO9001, ISO/IATF16949, ISO14001, IECQ QC080000. Orient Display takes around 18% market share in global automotive market and is No.1 in automotive capacitive touch screen.

In order to be convenient to our customers, Orient Display also provides some demo boards so that the customers can evaluate the displays quickly.

What Demo Board and LCD Display Board Orient Display Provides

Simple Demo Board

Our engineers can make unique demo boards so the customers can have a quick and visual impression of Orient Display’s products. Normally, these LCD Display Demo Boards are custom made with the unit cost of around $250. Our engineers can pre-load customers’ required pictures to the demo boards, however, customers cannot change the pictures inside the memory, only our engineers are able to change the pictures from factory. These demo boards are normally used to show unique LCD displays or custom-made LCD displays.

Universal Demo Boards

These demo boards are produced in batches with low unit cost ($50 to $100). They can be used to test a series of products.

• AMCT-1: For most of the character LCD displays.
• JAZZ-AB: For all the JAZZ series monochrome 128×64 graphic LCD displays.
• JAZZ-CUP-D1: For 2.4” and 2.8” TN type TFT LCD Displays
• JAZZ-CUP-D20: For 2.4” and 2.8” IPS type TFT LCD Displays.
• JAZZ-RGB-D1: For 3.5”, 4.3”, 5.0” and 7.0” TN type TFT LCD Displays with RGB interface.
• JAZZ-RGB-D20: For 3.5”, 4.3”, 5.0” IPS type TFT LCD Displays with RGB interface.
• JAZZ-RGB-D3: For 3.5”, 4.3”, 5.0” and 7.0” TN type TFT LCD Displays with RGB interface with Capacitive touch panels.

AGN Series Embedded Display

The customers can use AGN 3.5”, 4.3” and 7.0” products easily to produce demos or presentation to show their ideas in a couples of hours. They are great products to engineers to produce quick prototypes with their own graphic design. GUI Capability makes it possible for engineers to make a demo within hours. There’s no need to understand how to drive LCD. Orient Display provides tutorials on website.

HDMI TFT Display Modules

Orient Display provides 4.3”, 5.0”, 7.0” and 10.1” HDMI Raspberry PI compatible TFT display modules. They are small monitors which our customers can plug and play into their computers or laptops. They are great products to have a quick evaluation of Orient Display LCD displays. Custom made HDMI TFT displays are available.

Control Board

Orient Display engineers are working on demos with control board to realize complicated functionality with different kinds of interfaces, such as USB, HDMI, VGA, eDP, MIPI etc. The control boards can provide WIFI, ethernet, Bluetooth, IR, RF, camera (High Definition), fingerprint recognition, voice recognition, facial recognition etc. WinCE, Linux, Android.

Operating system kernel interface to all device drivers. Code is more complicated but only software engineers can do the job working with Orient Display engineers. Orient Display can make hardware and OS fitting the customer’s requirements.

Accessories

Orient Display also provides some accessories which are every convenient for our customers, such as ZIP connectors, cables, adaptor, transit boards etc.

If you have any questions about Orient Display Arduino TFT LCD displays. Please feel free to contact our engineers for details.
